12v DC Electric Fuel Oil Diesel Transfer Pump

Description:

Powered by DC 12V is a high efficiency diesel pump with small size, big flow, high delivery head and driven for easy operating. It is temperature resistant and anti-shock with a high quality protection rating of IP55. With inner bypass valve and excellent quality, it works by vehicle battery, with good self priming function, pump is also equipped with filter. It is really a practical and necessary tool.

Features:

1. Made of cast iron and coating surface, corrosion resistant and durable in using.
2. Powered by DC 12V, high efficiency with small size and big flow.
3. With inner bypass valve and excellent quality, it works by vehicle battery; with good self priming function, it is also equipped with filter to prevent debris from damaging the pump.
4. With protection rating of IP55, it is is temperature resistant and anti-shock.
5. It can be used with a fueling nozzle and filters for ensuring the flow of clean diesel or kerosene.

Specifications:

Material: Cast iron and coating surface
Color: Red & Black
Power: 160w
Voltage: 12V DC
Max Suction Distance: 5m
Max Head: 10m
Max Flow Rate: 40L/min
Hose Connection Size: 1" (25mm)
Pump Size: 18.8 x 9.5 x 9.5cm / 7.4" x 3.74" x 3.74"
Filter Size: 3.5 x 8.8cm / 1.38" x 3.46"
Other Detailed Size: As the picture show
Suitable for pumping diesel and kerosene, allows pumping of clean oil with low viscosity

Cautions:

1. The power source voltage should be confirmed to match the power input of the pump prior to connecting to the pump.
2. Voltage tolerance of +/- 5%.
3. Diesel or kerosenetransfer is in the direction of the arrow as indicated on the pump.
4. Be sure to have an air-tight seal on the suction hose so proper flow can be achieved. The filter screen should be installed on the end of the suction hose to prevent debris from damaging the pump.
5. The duty cycle of this pump is 30 minutes under normal usage. The pump has thermal protection and may shut off if the maximum operating temperature of the pump is achieved.

Package Included:

1 x Diesel Pump
1 x Micro Mesh Filter
2 x Fittings
2 x Clips
